The Aim.70 is a beautifully engineered extra minimal downlight suitable for both dry and humid interiors. An intensely deep black baffle combined with an extra slim aluminium powder coated bezel allows for a low glare and minimal architectural lighting.
The design gives 20° of tilt with 180° of pan, allowing for pinpoint accuracy of light. The Aim.70 has a superior designed heat sink, allowing for cool running while only requiring 58mm height clearance.
The fitting can accommodate a 15° 24° 36° or 60° beam, with Correlated Colour Temperatures (CCT) of a cool 4000K.
Aim.70 4000K Product Specification
| Material | Aluminium |
| Lumen Output | 780Lm |
| LED | HonourTEK HRA0607 9W DC250mA 36v |
| Lifespan | >50,000 hrs |
| CRI | >95 |
| Power Factor | >0.50 |
| Size | Ø68.5*58MM |
| Cutout | Ø62mm |
| Fire & Acoustic Rated | 60min |
| IP Rating | 20 |
| Working Temperature | -20°C – +40°C |
| Binning | 1 SDCM |
| Finish | White Powder Coat or Black |
